MSI Spatium M470 1TB PCIe 4.0 NVMe M.2 SSD
| Model Name | SPATIUM M470 PCIe 4.0 NVMe M.2 | |
| Capacity | 1TB | 2TB |
| Controller | PHISON E16 | |
| Flash Memory | 3D NAND | |
| DRAM Cache | 1GB DDR4 | 2GB DDR4 |
| Form Factor | M.2 2280 | |
| Interface | PCIe Gen4x4, NVMe 1.3 | |
| Compatibility | PCIe Gen4 / Gen3 / Gen2 / Gen1 | |
| Dimensions | 80.00mm (L) x 22.00mm (W) x 2.15mm (H) | |
| Sequential Read up to (MB/s) | 5000 | |
| Sequential Write up to (MB/s) | 4400 | |
| Random Read 4KB up to (IOPS) | 600,000 | |
| Random Write 4KB up to (IOPS) | 600,000 | |
| Maximum Operating Power (W) | 6.3 | 7.0 |
| Idle Power PS3 (mW) | 20 | 25 |
| Low Power L1.2 (mW) | 2 | |
| Operating Temperatures | 0°C – 70°C | |
| Storage Temperatures | -40°C – 85°C | |
| Terabytes Written (TBW) | 1600 | 3300 |
| Mean Time Between Failure (MTBF) | Up to 1,700,000 Hours | |
| Limited Warranty | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. | |
| Advanced Features | TRIM (Performance Optimization, OS support required) SMART (Self-Monitoring, Analysis and Reporting Technology) LDPC (Low Density Parity Check) ECC Algorithm End to End Data Path Protection APST (Autonomous Power State Transition) Pyrite (Encryption, Data Security) |
|
